Description
Accurate measurements and recordings of surface temperature and ambient conditions
Integrated camera instantly shows and documents measured values in photos
Transfers data via Bluetooth® with the Measuring Master App for easy storage and sharing of high-quality documentation
Dual Power Source technology allows for use with both a 12 V Li-ion battery or standard alkaline batteries
Specifications
- Measurement range: -40 °C … +1000 °C
- Measuring accuracy of IR: ±1.0 °C
- Optics (Ratio of meas. distance : meas. spot): 50:1
- Measuring distance: 50
- Measuring spot: 1
- Resolution: 0.1°C
- Measuring accuracy of relative humidity: ± 2 %
- Laser diode: Laser class 2, 635 nm
- Frame buffer (number of images): >200
- Memory type: Internal memory
- File format of image: .jpg
- Data transfer: MicroUSB, Bluetooth™, Bluetooth™ Smart
- Shock protection: 1m
- Supported Android devices: Smartphone with Android 4.0 or higher, Tablet with Android 4.0 or higher
- Supported iOS devices: iPad (3rd Gen. or higher), iPad Air (1st Gen. or higher), iPad mini (1st Gen. or higher), iPhone 4S or higher
- Display type: TFT LCD
- Size of display: 2,8"
- Operating temperature, from: -10°C
- Operating temperature, up to: 50°C
- Operating temperature: -10 – 50°C
- Storage temperature, from: -20°C
- Storage temperature, up to: 70°C
- Storage temperature: -20 – 70°C
- Working range, from: 0.1m
- Working range, up to: 5m
- Working range: 0.1 – 5m
- LED Laser Colour: Red
- Laser Class: 2
- Laser Diode: 635 nm, < 1 mW
Includes
- 1 x GIS 1000 C
- 4 x 1.5V (AA) Alkaline
- 1 x 120 cm camera cord
- Batteries
- 1 x Carry bag
- 1 x User Manual
Specification
Specifications
| Part No | 601083340 |
|---|---|
| Barcode | 3165140798624 |
| Brand | Bosch |
| Warranty | 6 Year |
| Product Length (mm) | 260 |
| Product Width (mm) | 180 |
| Product Height (mm) | 170 |
Videos & Manuals
Manuals
- Bosch Infared Scanner GIS1000C - Product Manual
